Bitumen

Bitumen, with specific grades (30/40, 40/50, 60/70, 85/100), offers varied penetration, softening points, and high ductility, making it ideal for construction and paving. Its low heating loss and specific flash point ensure durability in different conditions.

Category:

Description

Bitumen, as outlined in the provided specifications, is characterized by properties like specific gravity, penetration, softening point, ductility, and loss on heating. Depending on the grade (30/40, 40/50, 60/70, or 85/100), bitumen shows varying levels of penetration and softening points, indicating its suitability for different paving and construction applications. It maintains high ductility, minimal loss on heating, and specific flash and solubility properties, ensuring durability and performance under various environmental conditions.



No Characteristics Test Method 30/40 40/50 60/70 85/100
1 Specific Gravity @ 25°C ASTM_D3289 1.00 – 1.25 1.00 – 1.25 1.00 – 1.25 1.00 – 1.25
2 Penetration @25°C, 10 mm ASTM_D5 30 – 40 40 – 50 60 – 70 85 – 100
3 Softening Point, °C ASTM_D36 55 – 63 52 – 60 49 – 56 45 – 52
4 Ductility @ 25°C, cm ASTM_D113 Min 100 Min 100 Min 100 Min 100
5 Loss On Heating, % ASTM_D6 0.03 0.03 0.03 0.03
6 Drop in Penetration After Heating, % ASTM_D6 / D5 Max 20 Max 20 Max 20 Max 20
7 Spot Test AASHTO T 102 NEG NEG NEG NEG
8 Flash Point, °C ASTM_D92 Min 250 Min 250 Min 250 Min 250
9 Solubility in CS₂, % ASTM_D4 5.99 5.99 5.99 5.99
